The following diagram shows my preferred method for wiring a domestic 2-way lighting circuit. In this context, 2-way implies that two switches attach to the same light. In the above diagram, the Supply and Light cables are standard 3-core (Live, Neutral and Earth). The Switch cables are special 4-core used specifically for this type of circuit.
